Function, rubber sheet according to a use Shock absorbing rubber sheet (Ti-Hanenon®)
Features
- ・Excels in shock absorbency and vibration insulation.
- ・The impact resilience is 6 ~ 7%. (Measured Value.)
Applications
- ・Damping material: Protection of conveying equipment, stopper for precision positioning of conveyed goods, replacement of shock absorber.
- ・Floor material: Prevention of scattering and loss of dropped goods.
- ・Resonance reducing material for audio equipment: Insulation of player unit from external vibrations.
- ・Various vibration absorbing rubbers and cushioning material.(gasket, packing.)
Function | ・ Impact Absorption |
---|
(Ti-Hanenon ® is a registered trademark of our low repulsion foam rubber.)
Properties: Ti-Hanenon
Item Name | Properties | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
General Properties | Heat-Resistant Aging 100°C×72h |
Oil Resistance 100°C×72h |
Ozone Resistance Ozone 500ppb(50pphm) × 40°C×20% Elongation × 72h |
Impact Resilience % |
|||||||
Hardness Type A |
Tensile Strength at Break MPa {kgf/cm2} |
Elongation at Break % |
Hardness Change Type A |
Change Rate of Tensile Strength atBreak % |
Change Rate of Elongation at Break % |
Volume Change Rate % |
|||||
ASTM#1 % |
IRM903 % |
||||||||||
Ti-Hanenon | <65> | 62(49) | 3.6{38} | 840 | +3 | +11 | -8 | -3 | +13 | No change | 7 |
<35> | 35(25) | 6.2{63}*1 | 1000 or more*1 | +10 | 10.3*2 | 820*2 | -11 | +27 | C-4 | 6 |
JIS K 6250
- *1)The maximum value was indicated because the test piece was extended more than
measurement limit. - *2)Change rate was not able to be calculated because the measurement result of TB and EB
could not be obtained.Therefore, each measured value was indicated. - ●The above mentioned values are not standard values, but measured values.
Specification
Specification | Product Dimension (Standard Size) | ||
---|---|---|---|
Thickness mm | Width m | Length m | |
With embossed pattern on both surfaces | 2~10t | 1 | 2 |
●Please consult us on thickness and surface specification other than the above listed.
Please check here to find out the environmental compliance of this product.
●These descriptions can be altered for a reason of improvement without any notification.
●These descriptions shall be as of November 1, 2021.
